UV lamp 602856(UVL-19190 2P Y)

The bactericidal UV lamp 602856 (UVL-19190 2P Y) produced by our company is designed for operation in water disinfection systems. Due to the specific nature of this lamp, the number of on/off cycles is limited to 200 times.

You can also buy:

  • quartz sleeves for the lamp 602856.
  • power supply units for the lamp 602856.
  • installations and components.

We will manufacture equipment according to your specifications.

The inner surface of the lamp is coated with the UVL-LivePower+ compound. This technology allows for the prevention of rapid power loss in UV radiation, significantly extending the effective lifespan of the lamp.

More about the UVL-LivePower+ technology

Possible markings: 602856, Atlantic UV 05-2615, Aqua Treatment Services, Inc. ATS2-3232, ATS ATS2-3232, R Can S37RL-AM, R Can S80, R Can SM80, R Can SV50, Sterilight S37RL-AM, Sterilight S80, Sterilight SM80, Sterilight SV50, UV Technologies 602856, UV Technologies 650657, UV Technologies 650659, UV Technologies J, UV Technologies K Plus, Trojan UV Technologies Pro 30, UV Technologies Pro 50, UV Technologies UVMax J, UV Technologies UVMax K Plus, Viqua 0799932638060, Viqua 799932638060, Viqua PRO24-186, Viqua PRO24-186/2

Price
On request
in stock
Check with manager
Technical Characteristics
Lamp type Оzone-free quartz amalgam low-pressure UV lamp
Wavelength range 254 Nm
Wattage 190 w
Output UVC Watts 65 w
Total length 930 mm
Lamp Quartz Diameter 19 mm
Base diameter 23 mm
Rated Life 16000 hrs
Warranty and Delivery

We provide reliable delivery globally using a reputable transportation company. There is an option for door-to-door delivery or delivery to a pickup point. Warranty for the integrity during transportation is in effect.

Calculate
  • The warranty service life of UV lamps depends on the lamp type and is specified in the product passport. The number of switching on/off cycles affects the service life of the lamp. The recommended number is indicated in the passport. After the service life has elapsed, the lamp needs to be replaced (the light emitted from the product does not guarantee the preservation of the bactericidal effect). In case of premature failure, we guarantee lamp replacement and delivery to your address at our expense. Only a photo of the lamp will be required for confirmation, no additional paperwork is necessary.
We have over 20 years of experience in manufacturing.
Our equipment is installed in over 10,000 industrial facilities worldwide.
